RF Disc / Plate Capacitor

We have many years’ experience making RF capacitors for demanding applications. Thanks to our materials expertise and applications know-how our products offer proven reliability and longer operating life.

Our RF disc / plate capacitors are made from selected low and medium permittivity CLASS 1 ceramic dielectric materials chosen for characteristics including a high Q factor (low loss), high dielectric breakdown strength, low magnetic susceptibility and good capacitance-temperature stability.

As a result we are able to offer compact capacitors with higher power ( kVA) ratings, low levels of self-heating and minimal frequency drift. All our products are made using low self-inductance construction, which allows them to be used at higher frequencies, and are proven robust for long operational life.

RF disc / plate capacitors are ideal for industrial and high power applications including:

  • Radio broadcast transmitters
  • Induction and dielectric heating equipment
  • HF filter, by-pass and coupling and oscillating circuits
  • High power matching tuned circuits
  • Antenna coupling circuits
  • Plasma generators
  • High quality medical imaging systems (MRI)

RF disc / plate capacitors are available in disc sizes from 10-225mm diameter, with a wide range of capacitance-voltage combinations and ratings. Bespoke units can also be produced to customer’s specifications, including custom metalwork connections and resin-coated options.

For more information on standard or bespoke RF disc / plate capacitors for your project please contact us.

Discover more information in our brochures
Capacitors
Capacitors 3.5 kV Discs
EN
EN
259 KB,  pdf
Capacitors
5kV Discs
EN
EN
324 KB,  pdf
Capacitors
10kV Discs
EN
EN
317 KB,  pdf
Capacitors
10-15kV Discs
EN
EN
345 KB,  pdf
Capacitors
10-20kV Discs with Moisture Protection
EN
EN
264 KB,  pdf
